King Kutter Disc Bearings ST208-1N

new products

King Kutter Disc Bearings ST208-1N

ST208-1N Disc Harrow Bearing With Material Chrome steel Gcr15 can use with  1" Square shaft.

  • item no.:

    ST208-1N
  • lead time:

    30 days
  • product orgin:

    China ,Shanghai
  • shipping port:

    Ningbo,Shanghai,Guangzhou,Qingdao
  • MOQ:

    50
products details

King Kutter Disc Bearings ST208-1N Introduction :


DIMENSIONS:

BORE: 1.030"

O.D.(L&C) 4.750"

Inner Race Width: 1.50"

Width: 1.37"

Material :Chrome steel Gcr15

Seal type :Tri-Ply Seals


 ST208-1N Bearing Picture :


DISC HARROW UNIT
 ST208-1N bearing


We Also Can Produce other high quality Disc Harrow Bearing:



ST211-1 3/4 1–2 1.78 5.5 2.189 1.827 0.354 2.854 4.449 5.5 0.531
45.21 139.7 55.6 46.4 9 72.5 113 139.7 13.5
ST211-2 3/16 1–2 2.188 5.5 2.189 1.827 0.354 2.854 4.449 5.5 0.531
55.58 139.7 55.6 46.4 9 72.5 113 139.7 13.5
ST211-1 15/16 1–2 1.939 5.5 2.752 1.827 0.354 2.854 4.449 5.5 0.531
49.24 139.7 69.9 46.4 9 72.5 113 139.7 13.5
ST740 1 2.188 5.5 2.189 1.827 0.354 2.854 4.449 5.5 0.516
55.58 139.7 55.6 46.4 9 72.5 113 139.7 13.1
ST208-1R5BC 2 1.043 5 1.654 1.378 0.276 2.165 3.622 5
26.5 127 42 35 7 55 92 127
ST209-1 1/8 1–2 1.18 5 1.673 1.685 0.276 2.343 3.839 5 0.531
29.97 127 42.5 42.8 7 59.5 97.5 127 13.5
ST209-30S 1–2 1.234 5 1.673 1.685 0.276 2.343 3.839 5 0.531
31.35 127 42.5 42.8 7 59.5 97.5 127 13.5
ST209-1 1/4 1–2 1.299 5 1.673 1.685 0.276 2.343 3.839 5 0.531
33 127 42.5 42.8 7 59.5 97.5 127 13.5
ST209-40R 1–2 1.609 5 1.673 1.685 0.276 2.343 3.839 5 0.531
40.88 127 42.5 42.8 7 59.5 97.5 127 13.5
FD-211-RM 1–2 1.531 5.5 2 1.827 0.354 2.874 4.469 5.5 0.531
38.89 139.7 50.8 46.4 9 73 113.5 139.7 13.5
ST211-40S 2 1.609 5.5 2 1.827 0.354 2.874 4.469 5.5 0.531
40.88 139.7 50.8 46.4 9 73 113.5 139.7 13.5
DHU 40S-211 2 1.609 5.5 2 1.827 0.354 2.874 4.469 5.5
40.88 139.7 50.8 46.4 9 73 113.5 139.7
ST208-1N 2 1.024 4.764 1.503 1.378 0.276 2.165 3.622 4.686
26 121 38.18 35 7 55 92 119.02
ST208-1 1/8 2 1.18 4.764 1.503 1.378 0.276 2.165 3.622 4.686
29.97 121 38.18 35 7 55 92 119.02
ST208-1 1/8G 2 1.18 4.764 1.503 1.378 0.276 2.165 3.622 4.686
29.97 121 38.18 35 7 55 92 119.02
ST208-1 42LTB 2 1.024 4.764 1.654 1.378 0.276 2.165 3.622 4.686



 Application :

ST208-1N disc bearing can be used in agricultural machinery  ,such as  for disc harrows, planters, mowers, rakes, all types of balers, tillage, seeding and forage harvester equipment, combines, cotton pickers/stripers, and other agricultural equipment like silo unloaders and grain elevators.

  • Modern, Monroe Tuffline, IHC, King Kutter, and Howse



King Kutter
