King Kutter Disc Bearings ST208-1N

ST208-1N Disc Harrow Bearing With Material Chrome steel Gcr15 can use with 1" Square shaft.

item no.:
ST208-1N
lead time:
30 days
product orgin:
China ,Shanghai
shipping port:
Ningbo,Shanghai,Guangzhou,Qingdao
MOQ:
50

products details

King Kutter Disc Bearings ST208-1N Introduction :

DIMENSIONS:

BORE: 1.030"

O.D.(L&C) 4.750"

Inner Race Width: 1.50"

Width: 1.37"

Material :Chrome steel Gcr15

Seal type :Tri-Ply Seals

ST208-1N Bearing Picture :

We Also Can Produce other high quality Disc Harrow Bearing:

ST211-1 3/4	1–2	1.78	5.5	2.189	1.827	0.354	2.854	4.449	5.5	0.531
ST211-1 3/4	1–2	45.21	139.7	55.6	46.4	9	72.5	113	139.7	13.5
ST211-2 3/16	1–2	2.188	5.5	2.189	1.827	0.354	2.854	4.449	5.5	0.531
ST211-2 3/16	1–2	55.58	139.7	55.6	46.4	9	72.5	113	139.7	13.5
ST211-1 15/16	1–2	1.939	5.5	2.752	1.827	0.354	2.854	4.449	5.5	0.531
ST211-1 15/16	1–2	49.24	139.7	69.9	46.4	9	72.5	113	139.7	13.5
ST740	1	2.188	5.5	2.189	1.827	0.354	2.854	4.449	5.5	0.516
ST740	1	55.58	139.7	55.6	46.4	9	72.5	113	139.7	13.1
ST208-1R5BC	2	1.043	5	1.654	1.378	0.276	2.165	3.622	5
ST208-1R5BC	2	26.5	127	42	35	7	55	92	127
ST209-1 1/8	1–2	1.18	5	1.673	1.685	0.276	2.343	3.839	5	0.531
ST209-1 1/8	1–2	29.97	127	42.5	42.8	7	59.5	97.5	127	13.5
ST209-30S	1–2	1.234	5	1.673	1.685	0.276	2.343	3.839	5	0.531
ST209-30S	1–2	31.35	127	42.5	42.8	7	59.5	97.5	127	13.5
ST209-1 1/4	1–2	1.299	5	1.673	1.685	0.276	2.343	3.839	5	0.531
ST209-1 1/4	1–2	33	127	42.5	42.8	7	59.5	97.5	127	13.5
ST209-40R	1–2	1.609	5	1.673	1.685	0.276	2.343	3.839	5	0.531
ST209-40R	1–2	40.88	127	42.5	42.8	7	59.5	97.5	127	13.5
FD-211-RM	1–2	1.531	5.5	2	1.827	0.354	2.874	4.469	5.5	0.531
FD-211-RM	1–2	38.89	139.7	50.8	46.4	9	73	113.5	139.7	13.5
ST211-40S	2	1.609	5.5	2	1.827	0.354	2.874	4.469	5.5	0.531
ST211-40S	2	40.88	139.7	50.8	46.4	9	73	113.5	139.7	13.5
DHU 40S-211	2	1.609	5.5	2	1.827	0.354	2.874	4.469	5.5
DHU 40S-211	2	40.88	139.7	50.8	46.4	9	73	113.5	139.7
ST208-1N	2	1.024	4.764	1.503	1.378	0.276	2.165	3.622	4.686
ST208-1N	2	26	121	38.18	35	7	55	92	119.02
ST208-1 1/8	2	1.18	4.764	1.503	1.378	0.276	2.165	3.622	4.686
ST208-1 1/8	2	29.97	121	38.18	35	7	55	92	119.02
ST208-1 1/8G	2	1.18	4.764	1.503	1.378	0.276	2.165	3.622	4.686
ST208-1 1/8G	2	29.97	121	38.18	35	7	55	92	119.02
ST208-1 42LTB	2	1.024	4.764	1.654	1.378	0.276	2.165	3.622	4.686
ST208-1 42LTB	2

Application :

ST208-1N disc bearing can be used in agricultural machinery ,such as for disc harrows, planters, mowers, rakes, all types of balers, tillage, seeding and forage harvester equipment, combines, cotton pickers/stripers, and other agricultural equipment like silo unloaders and grain elevators.

Modern, Monroe Tuffline, IHC, King Kutter, and Howse

King Kutter
