F693 Flanged Miniature Bearing

new products

F693 Flanged Miniature Bearing

3 x 8 x 3 mm F693 ZZ bearing is a metric flanged ball bearing ,we can produce this bearings with Chrome steel or stainless steel material ,free sample can be provide for you to test in advance .

  • item no.:

    F693
  • lead time:

    5 days
  • product orgin:

    China
  • shipping port:

    NINGBO ,GUANGZHOU ,QINGDAO,SHANGHAI,Shanghai
  • MOQ:

    1000
products details

F693 Bearing Specification :

3X8X3 Flanged Bearing F693ZZ

Inner diameter: 3  MM

Outer diameter: 8 MM

Thickness: 4 M4

Race Material: AISI52100 Bearing Steel (Chrome steel Gcr15 ,bearing steel )

Ball Material: AISI52100 Bearing Steel (Chrome steel Gcr15 ,bearing steel )

Retainer:  Steel

Enclosure: Metal Shields or Rubber Seals


Bearing No.: F693Z, FL693ZZ, RF830ZZ, LF830-ZZ, F693.2ZJ1, F693.2Z, MF693ZZ, F693SS


Applicaition :F693 motor bearings


F693 2Z bearing
 F693-ZZ Bearings
F693 Flanged Bearing


We Can Produce Other Miniature Flanged Ball Bearing:


Model     Frange Diameter (D1) Width(b) Width of flange(c) Cr(N) Cor(N) Permit Speeding
(d) (D) open zz open zz open zz Grease Oil
    *1000rpm
F682zz 2 5 6.1 1.5 2.3 0.5 0.6 169 50 85 100
MF52zz 2 5 6.2 2 2.5 0.6 0.6 169 50 85 100
F692zz 2 6 7.5 2.3 3 0.6 0.8 330 99 75 90
MF62zz 2 6 7.2 2.5 2.5 0.6 - 330 99 75 90
MF72zz 2 7 8.2 2.8 3 0.6 0.6 386 129 63 75
F602zz 2 7 8.5 2.8 3.5 0.7 0.9 386 129 60 71
F682Xzz 2.5 6 7.1 1.8 2.6 0.5 0.8 209 74 71 80
F692Xzz 2.5 7 8.5 2.5 3.5 0.7 0.9 386 129 63 75
MF82X 2.5 8 9.2 2.5 - 0.6 - 558 180 60 67
F602Xzz 2.5 8 9.5 2.8 4 0.7 0.9 552 177 60 71
MF63zz 3 6 7.2 2 2.5 0.6 0.6 209 74 71 80
F683zz 3 7 8.1 2 3 0.5 0.8 311 112 63 75
MF83zz 3 8 9.2 2.5 3 0.6 - 395 141 60 67
F693zz 3 8 9.5 3 4 0.7 0.9 558 180 60 67
MF93zz 3 9 10.2 10.6 2.5 4 0.6 0.8 571 189 56 67
F603zz 3 9 10.5 3 5 0.7 - 571 189 56 67
F623zz 3 10 11.5 4 4 1 1 631 219 50 60
MF74zz 4 7 8.2 2 2.5 0.6 0.6 255 108 60 67
MF84zz 4 8 9.2 2 3 0.6 0.6 395 141 56 67
F684zz 4 9 10.3 2.5 4 0.6 1 641 227 53 63
MF104zz 4 10 11.2 11.6 3 4 0.6 0.8 711 272 48 56
F694zz 4 11 12.5 4 4 1 1 957 350 48 56
F604zz 4 12 13.5 4 4 1 1 957 350 48 56
F624zz 4 13 15 5 5 1 1 1301 488 40 48
F634zz 4 16 18 5 5 1 1 1340 523 36 43
MF85zz 5 8 9.2 2 2.5 0.6 0.6 218 90 53 63
MF95zz 5 9 10.2 2.5 3 0.6 0.6 431 169 50 60
MF105zz 5 10 11.2 11.6 3 4 0.6 0.8 431 169 50 60
MF115zz 5 11 12.5 - 4 0.8 1 716 282 45 53
F685zz 5 11 12.5 3 5 0.8 1 716 282 45 53
F695zz 5 13 15 4 4 1 1 1077 432 43 50
F605zz 5 14 16 5 5 1 1 1329 507 40 50
F625zz 5 16 18 5 5 1 1 1729 675 36 43
F635zz 5 19 22 6 6 1.5 1.5 2336 896 32 40
MF106zz 6 10 11.2 2.5 3 0.6 0.6 496 218 45 53
MF126zz 6 12 13.2 13.6 3 4 0.6 0.8 716 295 43 50
F686zz 6 13 15 3.5 5 1 1.1 1082 442 40 50
F696zz 6 15 17 5 5 1.2 1.2 1340 523 40 45
F606zz 6 17 19 6 6 1.2 1.2 2263 846 38 45
F626zz 6 19 22 6 6 1.5 1.5 2336 896 32 40
MF117zz 7 11 12.2 2.5 3 0.6 0.6 455 202 43 50
MF137zz 7 13 14.2 14.6 3 4 0.6 0.8 541 276 40 48
F687zz 7 14 16 3.5 5 1 1.1 1173 513 40 50
F697zz 7 17 19 5 5 1.2 1.2 1605 719 36 43
F607zz 7 19 22 6 6 1.5 1.5 2336 896 36 43
F627zz 7 22 25 7 7 1.5 1.5 3287 1379 30 36
MF128zz 8 12 13.2 13.6 2.5 3.5 0.6 0.8 543 274 40 48
MF148zz 8 14 15.6 3.5 4 0.8 0.8 817 386 38 45
F688zz 8 16 18 4 5 1 1.1 1252 592 36 43
F698zz 8 19 22 6 6 1.5 1.5 2237 917 36 43
F608zz 8 22 25 7 7 1.5 1.5 3293 1379 34 40
F689zz 9 17 19 4 5 1 1.1 1327 668 36 43
F699zz 9 20 23 6 6 1.5 1.5 2467 1081 34 40
F6700zz 10 15 16.5 16.5 3 4 0.8 0.8 850 430 14 16
F6800zz 10 19 21 5 5 1 1 1700 800 35 42
F6900zz 10 22 25 6 6 1.5 1.5 2611 1223 31 40
F6701zz 12 18 19.5 19.5 4 4 0.8 0.8 922 512 12 14
F6801zz 12 21 23 5 5 0.8 1 1911 1041 33 39
F6901zz 12 24 26.5 6 6 1 1.5 2831 1411 31 36
