The Features of Stainless Steel Pillow Block Bearing

The Features of Stainless Steel Pillow Block Bearing

  • 2019-07-08

What are the characteristics of stainless steel outer spherical bearings


Stainless steel outer spherical bearings are widely used, and the application environment is also very harsh, such as mud, dust, humidity and high temperature environments.


The following are mainly the characteristics of the outer spherical surface of the stainless steel bearing


1. The stainless steel outer spherical bearing with seat can work with two bearing seats with different shafts, and the maximum automatic adjustment angle can reach 2°.


2. The stainless steel outer spherical bearing with seat has good rotation accuracy; it can be easily relubricated. The clearance is larger than that of a deep groove ball bearing of the same size, so the temperature difference has little effect on its accuracy.


3. The inner diameter of the stainless steel outer spherical bearing adopts the "+" tolerance to form a clearance fit with the shaft. The bearing is fixed on the shaft through the top wire, eccentric sleeve or adapter sleeve on the upper side of the inner ring, reducing the The accuracy of the shaft is required, and it is extremely convenient to install or replace the bearing.


4. The stainless steel outer spherical bearing with seat consists of an outer spherical bearing and a bearing seat. When in use, there is no need to design the bearing box separately, the size is small, the structure is simple, and it can be directly installed on the design part of the main machine with bolts, which is convenient to use.


5. The stainless steel belt seat outer spherical bearing is generally pre-filled with grease, and adopts double-layer or triple-layer sealing. It is suitable for use in occasions with more dust, muddy water and corrosive media, which is conducive to the operation of the host.


6. The stainless steel bearing seat has an integral structure with large carrying capacity and good rigidity. The bearing and the bearing seat can be interchanged, that is, the same bearing seat can be installed with various types of bearings; similarly, the same bearing can be equipped with various types of bearing seats.


ZZ BEARINGS is a pillow bearing bearing ,insert bearing manafacturer in China ,we can produce outer spherical bearing for you such as UC205-16 ,SA205 ,SA208,UEL209,UC208,UC312.
